CAMARA IP HIKVISION iDS-TCV900-HI/25/H1

340178301

Cámara Bullet, resolución 9MP, lente Fija, óptica 25mm, IR 30m, N/A, IP67, IK10, sensibilidad 0.001 Lux, ANPR, Sin Wifi, Alarma In/Out, , soporta memoria SD.

Fuera de stock, consultar plazo

Iniciar sesión para ver precios

Envío gratis*

*En compras superiores a 200€ en Península y Baleares.

Productos Bajo Pedido

Podemos suministrar cualquier producto sin stock.Consulta plazo.

Devoluciones

30 días para cambio odevoluciónde productos no usados.

Pagos 100% seguros

Transferencia bancaria, tarjeta de crédito/débito, PayPal, Google Pay.

Detalles del producto

CAMARA IP HIKVISION iDS-TCV900-HI/25/H1

Specification

Camera	Image Sensor	9 MP (1'' GMOS )
	Max. Resolution	4096 × 2160
	Min. Illumination	Color: 0.001 Lux @ (F1.4, AGC ON), B/W: 0.0005 Lux @ (F1.4, AGC ON), 0 Lux with IR
	Shutter Time	7 us to 20000 us
	Day & Night	IR cut filter
Lens	Lens Type	Fixed focal lens, 25 mm, Varifocal lens, motorized lens, 11 to 40 mm
	Focal Length & FOV	25 mm, horizontal FOV 31.6°, vertical FOV 17.0°, diagonal FOV 35.4°, 11 to 40 mm, horizontal FOV 61.8° to 23.5°, vertical FOV 32.4° to 12.2°, diagonal FOV 70.0° to 26.8°
	Focus	Auto,Manual
	Aperture	F1.6-20/F1.8-1.9
Illuminator	Built-in Supplement Light Type	IR light
	Light Bead	3
	Built-in Supplement Light Range	Up to 30 m
	IR Wavelength	850 nm
	External Supplement Light	Strobe and flash light
Video	Main Stream	50 Hz: 50 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (4096 × 2160, 3840 × 2160, 3392 × 2008, 3072 × 1728, 2688 × 1520, 1920 × 1200, 1920 × 1080, 1280 × 720)
	Sub-Stream	50 Hz: 50 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (3392 × 2008, 2688 × 1520, 1920 × 1080, 1280 × 720)
	Third Stream	50 Hz: 50 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
	Video Compression	Main stream: H.265/H.264/MJPEG, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG
	Video Bit Rate	32 Kbps to 64 Mbps
	H.264 Type	Baseline profile/Main profile/High profile
	H.265 Type	Main Profile
Network	Protocols	TCP/IP,ICMP,HTTP,HTTPS,FTP,DNS,RTP,RTSP,RTCP,NTP,SNMP,802.1X,IPv4/IPv6,UDP,ISUP,ARP,IGMP,SMTP
	Simultaneous Live View	Up to 10 channels
	API	ISAPI,SDK,ISUP,ONVIF (PROFILE S, PROFILE G, PROFILE T, PROFILE M)
	User/Host	Up to 16 users,3 user levels: administrator, operator, and user
	Security	Password protection,Complicated password,HTTPS encryption,Control timeout settings,802.1X authentication (EAP-PEAP, EAP-LEAP, EAP-MD5),Basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for ONVIF
	Network Storage	Micro SD/TF card (512 GB),Local storage,CVR,NVR,ANR
	Client	Hik-Central Master,Hik-Central Pro,HikCentral Master Lite
	Web Browser	Chrome V61+, IE9 to IE11, Firefox V40+, Edge
Image	Image Settings	Saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser.
	Day/Night Switch	Auto,Schedule,Manual
	SNR	60 dB
	Image Enhancement	BLC,3D DNR
Interface	Ethernet Interface	2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port(s)
	On-Board Storage	Built-in memory card slot, supporting microSD/SDHC/SDXC card, up to 512 GB
	Alarm	2 input interfaces (T1, SYNC), 7 output interfaces
	RS-485	3 RS-485 interfaces (half duplex, HIKVISION)
	RS-232	1 RS-232 interface
	USB	1 USB 2.0 interface
Event	Basic Event	HDD error,Network disconnected,IP address conflict, traffic light detector exception
Road Traffic and Vehicle Detection	Coverage	Up to 3 lane(s)
	Trigger Mode	External I/O trigger/Radar trigger/Video trigger
	Smart Function	License plate recognition,Vehicle type classification,Vehicle color recognition,No-plate vehicle capture,Moving direction detection
	LPR Countries/Regions	Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain, Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria, Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Myanmar, India, Mongolia, Cambodia, Laos, Bangladesh, Nepal, Sri Lanka, America: Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala, Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian, Belgium, Luxembourg, Albania, Kosovo, Serbia, Romania, Montenegro, Denmark, Finland, Sweden, Slovenia, Portugal, Malta, Cyprus, Iceland, Liechtenstein, Bosnia and Herzegovina, Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia, Turkmenistan, Tajikistan
	No License Plate Detection	Supported
	Accuracy (Under recommended installation and lighting conditions)	Capture rate > 99%, Vehicle moving direction recognition accuracy > 98.5%, LPR accuracy > 98%, Mistaken capture rate < 2%
	Motorcycle LPR	Supported
	Vehicle Type	Car,Van,Bus,Truck,Light Truck,SUV(MPV),Pickup,Motorcycle,Tricycle
	Vehicle Color	Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only.
	Vehicle Manufacturer	212 Manufacturers: AC SCHNITZER, AITO, APOLLO, Ashok Leyland, Audi, Aston Martin, Acura, Ankai, Ayvip, Alfa Romeo, Asiastar, Artega, ARCFOX, BAIC, Beiben Truck, BLUECAR, Bedford, Benz, BMW, BYD , Bufori, Buick, Bently, Brabus, Bugatti, Borgward, BONLUCK, Besturn, CADILLAC, Celis, Chevrolet, Citroen, Chery, Chrysler, Chang an, CNHTC, CHTC, Caterham, Conquest, C&C Trucks, CAMC, DAIHATSU, DMC, DS, Dacia, Dongnan, Dodge, Dongwo, Denza, Dongfeng, Daewoo, Dima, Denway, DORCEN, Eicher, Emgrand, Equss, EXEED, Ford, FORO, Fornasari, Ferrari, Fuqi, Fiat, Fisker, FQT Motor, Foton, FAW, FORLAND, FUSO, Force Motors, Fxauto, Faralli Mazzanti, GAC, Great Wall, GMC, Geely, Geometry, Hyundai, HENNESSEY, HINO, Honda, Haima, Haval, Hongqi, Isuzu, Infiniti, Iveco, IAT, IM, JAC, JBC, JEEP, Jaguar, JMC, JETOUR, JETTA, Joylong ,Koenigsegg, KIA , Kia-Borrego, King Long, Kama, KTM, LEVC, Lexus, Land Rover, Lincoln, Lamborghini, Lotus, Luxgen, Levdeo, Leopaard, Lynk & Co , Lada, Leading Ideal, LEAPMOTOR, LUMMA, Lorinser, Land Wind, MAN Trucks , MAXUS, MG, MINI, Mahindra, Mitsuoka, Maserati, Meiya , McLaren, Maybach, Mazda, Morgan, Mitsubishi, Mustang, Marvel R, Maple, MANSORY, Modern, NOMA, Nissan, Norinco, Neoplan, NIO, NETA, Opel, Ora, Oushang, Perodua, Porsche, Peugeot, PGO, Proton, Pagani, Polestar, POCCO, Qoros, RAM, Rolls-Royce, Renault, Roewe, Rohens, Ranz, Ruilan, Radar, Renault Samsung, SAAB, SCANIA , SCION, SMART, SML ISUZU, Suzuki, SAIC Datong, Subaru, Skoda, Startek, Soyat, Seat , SWM, Sany, SsangYong, Sojen, Silver, SATE, SOL, Skyworth, SGMW, SITECH DEV, TATA, Tankar, Tesla, Trumpchi, Techart, Toyota, UD, UAES, Volkswagen, VINFAST, Venucia, Volvo, VOYAH, VeiculoLongo, Weltmeister , XCMG, Xinyuan, XPENG, Yutong, YAMAHA, Zhonghua, Zotye, Zhinuo, ZEEKR, Zenvo
	License Plate Color Recognition	Customized to support
	U-Turn	Supported (only E-Police mode)
	Red Light Running	Supported (only E-Police mode)
	Failing to Yield for Pedestrians	Supported (only E-Police mode)
	Stop Vehicle on Intersection	Supported (only E-Police mode)
	Not Following Directional Sign	Supported (only E-Police mode)
	Driving on Lane Line Detection	Supported (only strobe light mode)
	Lane Change Detection	Supported (only strobe light mode)
	Wrong-Way Driving Detection	Supported
	Emergency Lane Occupation	Supported (truck forbidden lane, emergency lane, urban bus lane)
	Seatbelt Detection	Supported (with flash supplement light)
	Phone Call Detection	Supported (with flash supplement light)
	Capture Speed Range	10 to 320 km/h
General	Operating System	Linux
	Power	AC 100 V to 240 V, 2.9 A, max. 32 W, 3-core terminal block ,DC 24 model:DC 24 V, 2 A, max. 47 W, 2-core terminal block
	Material	Aluminum alloy
	Dimension	501.0 mm × 175.6 mm × 144.6 mm (19.72" × 6.92" × 5.69") (L × W × H)

Parámetros principales

Modelo del producto

iDS-TCV900-HI/25/H1

Alarma Cámara

Alarma In/Out

Audio

N/A Audio

Lente

Fija

Óptica

25mm

Protección Cámaras

IK10, IP67

Tipo de cámara

Bullet

Utilidad de la cámara

ANPR

Sensibilidad Lumínica

0.001 Lux

Iluminación

IR 30m

Tarjeta SD

Admite SD

WDR

N/A

Wifi

Sin Wifi

Soporte a Pared

N/A

Soporte a Techo

N/A

Soporte a Esquina

N/A

Soporte a Poste

N/A

Soporte Colgante

N/A

Soporte a prueba de agua

N/A

Caja de conexiones

N/A

Otros Soportes

N/A

Funciones Inteligentes

ANPR

PoE / PoC

N/A

Resolución

9MP

Tecnología

Marca

Hikvision CCTV

Gama

Hikvision Soluciones

Descargas

Datasheet_iDS-TCV900-HI-25-H1_340178301

Guia_iDS-TCV900-HI-25-H1_340178301
