CAMARA IP HIKVISION DS-2XM6222G1-IM/ND(2.8mm)

Cámara

• Velocidad de obturación1/3 s to 1/100,000 s

• P/NPAL: 25fps NTSC: 30fps

• Día y NocheIR Cut Filter

• Ajuste de ánguloPan: -20° to 0°, Tilt: -15° to 25°

• Balance de blancosSupport 4 white balance configurations: fluorescent lamp, incandescent lamp, warm lamp and natural light; Support manual/automatic white balance adjustment.

Lente

• Longitud focal2.8mm/4mm/6mm

• Focal Length & FOV2.8mm: horizontal FOV 105°, vertical FOV 56°, diagonal FOV 126° 4mm: horizontal FOV 87°, vertical FOV 44°, diagonal FOV 104° 6mm: horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62°

• Montura del lenteM12

• EnfoqueManual focus

• Max. Aperture2.8/4/6mm : F1.6

Iluminador

• Tipo de luz suplementariaInfrared fill light lamp

• Luz de suplemento inteligenteSupport

• IR Wavelength850 nm

• Rango IRUp to 10 m

Vídeo

• Max. Resolución1920 x 1080

• Main stream50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720)

• Sub-stream50Hz: 25 fps (704 x 576, 640 x 480, 352 x 288, 320 x 240) 60Hz: 30 fps (704 x 576, 640 x 480, 320 x 240)

• Third Stream50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720)

• Compresión de videoMain stream: H.264, H.265, H.264+, H.265+ Sub-stream: H.264, H.265, MJPEG, H.264+, H.265+ Third stream: H.264, H.265 ,H.264+, H.265+

• Vídeo bitrateMain Stream: 256 Kbps to 12288Kbps Sub-Stream: 256 Kbps to 4096Kbps Third Stream: 256 Kbps to 12288Kbps

• Tipo H.264BaseLine Profile/Main Profile/High Profile

• Tipo H.265Main Profile

• Bit Rate ControlConstant Bit Rate, Variable Bit Rate

• Stream TypeMain stream, sub stream, third stream

• Codificación de video escalable (SVC)H.264 and H.265 encoding

• Region Of Interest (ROI)Support 2 fixed region for (main/sub) stream

Red

• ProtocolosTCP/IP, HTTP, HTTPS, DHCP, DNS, DDNS , RTSP, SNMP, QOS, ISUP5.0, ISUP2.0

• Vista en vivo simultáneaUp to 8 channels

• APIONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK

• User ManagementUp to 16 users, 3 levels: Administrator, Operator and User

• Navegador webIE8+, Chrome45+, Edge41+, Firefox45+

Imagen

• Wide Dynamic Range (WDR)120 dB

• Configuración de imagenSupport rotation mode. Brightness, contrast, saturation and sharpness can be adjusted by browser and client software.

• Interruptor día/nocheDay/Night/Auto/Schedule

• SNR> 50 dB

• Mejora de la imagenBLC,HLC, 3D DNR

• Máscara de privacidadEnables configuration, and supports drawing of up to 4 areas

• Superposición de imagenSupport image overlay, uploading images, enabling, coordinates, etc.

• Recorte objetivoSupport (only the third stream)

• Compensación de luz de fondo (BLC)Support up, down, left, right, center and custom backlight compensation adjustment

Interfaz

• Salida de VídeoNot supported

• Ethernet Interface-ID: 1 RJ45 10M/100M self-adaptive Ethernet port -IM/ND, IDM: 1 four-core M12 aviation plug

• Reset KeySupport

• Tipo de interfazInterpolate

• TF Card StorageBuilt-in Micro TF Slot, up to 256 GB(not for baseline. Note the Micro-TF card capacity when ordering)

Evento

• Método de enlaceUpload to FTP, notify monitoring center, send email, trigger recording

• Evento BásicoMotion detection, video tampering alarm

• Evento inteligenteLine crossing detection, Intrusion detection, Region entrance detection, Region exiting detection, Unattended baggage detection, Object removal detection, Object detection: detects faces and upload images Scene change detection, defocus detection

General

• Dimensión del productoCamera: Φ 78.8 mm × 81.6mm x 63.8 mm (3.1″ × 3.2″ x 2.5″)

• alimentaciónPoE: 0.30 A to 0.20 A, max: 7.5 W DC: 0.83 A to 0.21 A, max: 7.5 W

• Dimensión del paquete174 mm × 111 mm × 101mm (6.85″ × 4.37″ × 3.98″)

• Peso del ProductoApprox. 330 g (0.7 lb.)

• Condiciones de inicio y funcionamiento-30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing)

• IdiomaEnglish, French, German, Russian, Italian, Korean, Portuguese, Spanish, Turkish, Polish, Czech

• Función generalAnti-flicker, heartbeat, mirror

• Reinicio de softwareSupport

• Fuente de alimentación-ID: 9-36V& PoE (802.3af, 36 V to 57 V) -IDM: 9-36V& PoE (802.3af, 36 V to 57 V) -IM/ND: PoE (802.3af, 36 V to 57 V)

• Interfaz de energía-ID: Ø 5.5 mm coaxial power plug, DC power supply, or PoE power supply -IM/ND: four-core M12 aviation plug, PoE power supply

• Longitud del cable50 cm

Certificaciones

• ClaseClass B

• EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);

• SeguridadUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013);

• AmbienteCE-RoHS (2011/65/EU);

• Electrical Safety ProtectionIP68 (IEC 60529-2013)

• Automotriz y ferroviarioEN50155-2017(EN 50155:2017, EN 50121-3-2:2016, IEC 60068-2-1:2007, IEC 60068-2- 2:2007, IEC 60068-2-30:2005, IEC 61373:2010); EN45545 (EN 45545-2:2013+A1:2015); E-MARK (ECE R10)
