CAMARA IP HIKVISION DS-2SE4C425MWG-E(14F0)

Sensor de imagen[Bullet channel]: 1/3" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive scan CMOS

Max. Resolución[Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440

Iluminación mínima[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

Velocidad de obturación1 s to 1/30,000 s

Día y NocheICR

Zoom[PTZ channel] 25 × optical, 16 × digital

Obturador lentoyes

Longitud focal[Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical

FOV[Bullet channel]: Horizontal field of view: 96.1°, Vertical field of view: 52.1°，Diagonal field of view: 113.3°; [PTZ channel]: Horizontal field of view: 55° to 2.4° (wide-tele), Vertical field of view: 33° to 1.4° (wide-tele), Diagonal field of view: 61.5° to 2.8° (wide-tele)

Enfoquesemi-auto||manual||auto

Apertura[Bullet channel]: F1.0; [PTZ channel]: F1.6

Velocidad del Zoom[PTZ channel]: approx. 3.6 s

Tipo de luz suplementaria[PTZ channel]: IR; [Bullet channel]: White Light

Rango de luz suplementaria[PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m

Luz de suplemento inteligenteYes

Rango de movimiento (pan)360°

Rango de movimiento (tilt)-15° to 90° (auto flip)

Velocidad de movimiento horizontal (pan)pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s

Velocidad de vertical (tilt)tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s

Proportional Panyes

Preajustes300

Congelación preestablecidayes

Escaneo de patrulla8 patrols, up to 32 presets for each patrol

Patrón de escaneo4 pattern scans

Acción del parquepreset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan

Posicionamiento 3Dyes

Pantalla de estado de PTZyes

Tarea programadapreset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output

Memoria de apagadoyes

Main stream[Bullet channel]: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) [PTZ channel]: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-stream[Bullet channel]: 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) [PTZ channel]: 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream[Bullet channel]: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) [PTZ channel]: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Compresión de vídeoH.265||H.264||MJPEG

Vídeo bitrate32 kbps to 16384 kbps

Tipo H.264baseline profile||main profile||high profile

Tipo H.265main profile

Codificación de video escalable (SVC)yes

Región de interés (ROI)8 fixed regions for each stream

Compresión de audioG.711,G.722.1,G.726,MP2L2,PCM,AAC-LC

Velocidad de bits de audio32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC)

Frecuencia de muestreo de audio8 kHz,16 kHz,32 kHz,48 kHz

Filtro de ruido ambientalyes

ProtocolosIPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour||WebSocket||WebSockets

Vista en vivo simultánea20

APIOpen Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

Usuario/operador32

SeguridadAuthenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter

Almacenamiento en redNAS (NFS, SMB/ CIFS)|| ANR

ClienteiVMS-4200||Hik-Connect

Navegador webIE 10+, Chrome 57+, Firefox 52+, Safari 12+

Interruptor de parámetros de imagenYes

Configuración de imagensharpness, saturation, brightness, contrast

Interruptor día/nocheday, night, auto, scheduled-switch

Wide Dynamic Range (WDR)120 dB

SNR≥ 52 dB

DesempañarDigital defog

Image StabilizationEIS

Mejora de la imagenBLC,HLC,3D DNR

Máscara de privacidad[Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable

Enfoque regionalYes

Exposición regionalYes

Ethernet InterfaceRJ45, self-adaptive 10M/100M Ethernet port

Almacenamiento a bordoBuilt-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB

Audio1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω

Alarma1 alarm input, 1 alarm output

Reiniciaryes

Evento Básico[PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)

Evento inteligente[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection

Linkage[Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan)

Captura de la cara[Bullet channel] no,[PTZ channel] yes

alimentación12VDC, PoE+

DimensiónØ 166 mm × 375 mm (Ø 6.5" × 14.7")

Approx. 2.4 kg (13.2 lb.)

MaterialADC12

Operating Condition-30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH

Función generalmirror,password protection,watermark,IP address filter

DemistaDemist by heating the glass

Consumo de energía y corrienteMax. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light

ProtecciónIP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
