CAMARA IP HIKVISION DS-2SE4C425MWG-E/26(F0)

Cámara

• Sensor de imagen[Bullet channel]: 1/2.5" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive scan CMOS

• Max. Resolución[Bullet channel] 3632 × 1632, [PTZ channel] 2560 × 1440

• Iluminación mínima[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR

• Velocidad de obturación1 s to 1/30,000 s

• Día y NocheICR

• Zoom[PTZ channel] 25 × optical, 16 × digital

• Obturador lentoyes

Lente

• Longitud focal[Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical

• FOV[Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°; [PTZ channel]: Horizontal field of view: 55° to 2.4° (wide-tele), Vertical field of view: 33° to 1.4° (wide-tele), Diagonal field of view: 61.5° to 2.8° (wide-tele)

• Enfoquesemi-auto||manual||auto

• Apertura[Bullet channel]: F1.0; [PTZ channel]: F1.6

• Velocidad del Zoom[PTZ channel]: approx. 3.6 s

Iluminador

• Tipo de luz suplementaria[PTZ channel]: IR; [Bullet channel]: White Light

• Rango de luz suplementaria[PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m

• Luz de suplemento inteligenteYes

• PTZ

• Rango de movimiento (pan)360°

• Rango de movimiento (tilt)-15° to 90° (auto flip)

• Velocidad de movimiento horizontal (pan)pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s

• Velocidad de vertical (tilt)tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s

• Proportional Panyes

• Preajustes300

• Congelación preestablecida yes

• Escaneo de patrulla 8 patrols, up to 32 presets for each patrol

• Patrón de escaneo 4 pattern scans

• Acción del parque preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan

• Posicionamiento 3D yes

• Pantalla de estado de PTZ yes

• Tarea programada preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output

• Memoria de apagadoyes

Vídeo

• Main stream[Bullet channel] 50 Hz：25 fps（3632 × 1632，3680 × 1656） 60 Hz：30 fps（3632 × 1632，3680 × 1656） [PTZ channel] 50 Hz：25 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720） 60 Hz：30 fps（2560 × 1440，1920 × 1080，1280 × 960，1280 × 720）

• Sub-stream[Bullet channel] 50 Hz：25 fps（1200 × 536，960 × 432） 60 Hz：30 fps（1200 × 536，960 × 432） [PTZ channel] 50 Hz：25 fps（704 × 576，640 × 480，352 × 288） 60 Hz：30 fps（704 × 480，640 × 480，352 × 240）

• Third Stream[Bullet channel] No [PTZ channel] 50 Hz：25 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 576，640 × 480，352 × 288） 60 Hz：30 fps（1920 × 1080，1280 × 960，1280 × 720，704 × 480，640 × 480，352 × 240）

• Compresión de vídeoH.265||H.264||MJPEG

• Vídeo bitrate32 kbps to 16384 kbps

• Tipo H.264baseline profile||main profile||high profile

• Tipo H.265main profile

• Codificación de video escalable (SVC)H.264 and H.265 encoding

• Región de interés (ROI)8 fixed regions for each stream

Audio

• Compresión de audioG.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3

• Velocidad de bits de audioMP2L2: 16 kHz, 32 kHz, 48 kHz; AAC-LC: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz; MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz

• Frecuencia de muestreo de audioMP2L2: 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 144 Kbps, 160 Kbps, 192 Kbps, AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps , MP3: 8Kbps, 16Kbps, 24Kbps, 32Kbps, 40Kbps, 48Kbps, 56Kbps, 64Kbps, 80Kbps, 96Kbps, 112Kbps, 128Kbps, 160Kbps, 192Kbps, 224Kbps, 256Kbps, 320Kbps

• Filtro de ruido ambientalyes

Red

• ProtocolosIPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour||WebSocket||WebSockets

• Vista en vivo simultánea20

• APIISAPI,SDK,ISUP,ONVIF

• Usuario/operador32

• SeguridadAuthenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter

• Almacenamiento en redNAS (NFS, SMB/ CIFS)|| ANR

• ClienteiVMS-4200||Hik-Connect

• Navegador webIE11+,Chrome57+,Firefox52+,Safari12+,Edge79.0.309.65+

Imagen

• Interruptor de parámetros de imagenYes

• Configuración de imagensharpness, saturation, brightness, contrast

• Interruptor día/nocheday, night, auto, scheduled-switch

• Wide Dynamic Range (WDR)120 dB

• SNR≥ 52 dB

• DesempañarDigital defog

• Image StabilizationEIS

• Mejora de la imagenBLC,HLC,3D DNR

• Máscara de privacidad[Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable

• Enfoque regionalYes

• Exposición regionalYes

Interfaz

• Ethernet InterfaceRJ45, self-adaptive 10M/100M Ethernet port

• Almacenamiento a bordoBuilt-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB

• Audio1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω

• Alarma1 alarm input, 1 alarm output

• Reiniciaryes

Evento

• Evento Básico[PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)

• Evento inteligente[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection

• LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,audible warning,and PTZ actions (such as preset, patrol scan, pattern scan)

• Smart LinkagePanorama Linkage

• Deep Learning Function

• Captura de la caraDetects up to 5 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture

General

• alimentación12VDC, PoE+

• DimensiónØ 166 mm × 375 mm (Ø 6.5" × 14.7")

• Approx. 2.4 kg (13.2 lb.)

• MaterialADC12

• Operating Condition-30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH

• Función generalmirror,watermark,password protection

• DemistaDemist by heating the glass

• Consumo de energía y corrienteMax. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light

Certificaciones

• Protección IP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
