MONITOR INTERACTIVO HIKVISION DS-D5C98RB/A (EDLA)

Product Model

Product Model

DS-D5C98RB/A

Display

Screen Size

98 inch

Backlight

DLED

Pixel Pitch

0.5622 (W) × 0.5622 (H) mm

Resolution

3840 × 2160 @60 Hz

Brightness

600 cd/m² (Typ.)

Color Depth

10 bit

Display Color

1.07 G

Response Time

5 ms

Panel Type

VA

Contrast Ratio

5000:1 (Static) 30,000:1 (Dynamic)

Color Gamut

72% NTSC (CIE1931) (Typ.)

Refresh Rate

60 Hz

Viewing Angle

178° (H)/178° (V)

Aspect Ratio

16:9

Surface Hardness

9H (Pencil) 7 (Mohs)

Surface Glass

Anti-Glare Glass

Surface Haze

25% Haze

Glass Bonding Method

Zero Lamination

Display Area

2158.848 mm × 1214.352 mm

Working Duration

7 × 16 H

Transmittance

88% ± 3

Lifespan

50,000 hours

Touch

Type

Infrared Touch Screen

Touch Point

Up to 50-point multi-touch

Touch Response Time

≤ 2 ms

Minimum Touch Object

≥ 1.5 mm (≥ 90% touching area)

Touch Precision

± 0.5 mm (≥ 90% touching area)

Touch Resolution

32767 × 32767

Built-in System

Operation System

Android 13.0

Memory

8 GB

Built-in Storage

128 GB

Processor

Quad-core Cortex-A76 × 4（2.4 GHz）and quad-core Cortex-A55 × 4（1.8 GHz）

GPU

Mali-G610 MC4

HDCP Version

2.3

Internal Function

Loudspeaker

Built-in 2 × 20 W + 25 W loudspeaker;

Bluetooth

Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.1

NFC

Support screen mirroring by Android phones

Light Sensor

Yes

Interface

Video & Audio Input

HDMI In (HDMI 2.0) × 3, VGA In × 1, DP In (DP 1.2) × 1, Audio In × 1

Video & audio output

HDMI Out (HDMI 2.0) × 1, Audio Out × 1, SPDIF Out × 1

Control interface

TOUCH-USB 3.0 × 3, RS232 × 1

Network Interface

LAN (1000 Mbps) × 2 WIFI AP & Station, 2.4G/5G WIFI 6, IEEE 802.11 a/b/g/n/ac/ax  2 × 2 MIMO (2.4 GHz and 5 GHz) authentication protocols WEP, WPA, WPA2, PSK and 802.1X EAP

Data Transmission Interface

USB 3.0 × 4, USB 2.0 × 1, Type-C × 2 (Type-C supports USB 2.0, DP 1.2, and charging functions; side charging 15 W, front charging 65 W)

Power

Power Supply

100 to 240 VAC, 50/60 Hz

Standby Consumption

≤ 0.5 W

Average Consumption

< 325 W

Working Environment

Working Temperature

0 °C to 40 °C (32 °F to 104 °F)

Working Humidity

10%~90% RH

General

VESA

1000 mm × 400 mm (4 × M8-20 mm)

Product dimensions

2219.8 mm × 1336.4 mm × 105.7 mm

Accessory

Wall mount bracket, hook, user manual, touch writing pen, packing list, 3 M touch USB cable, 3.5 M HDMI cable (2.0), power cable , bluetooth remote control.

Package Dimensions (W × H × D)

2520 mm × 1700 mm × 330 mm

Net Weight

94 kg

Gross Weight

137 kg
