CAMARA IP HIKVISION DS-2CD6D44G1-IZS

Especificaciones técnicas:

• Cámara

• Sensor De Imagen 1/3" Progressive Scan CMOS

• Max. Resolución 2688 × 1520

• Iluminación Mínima Color: 0.005 Lux @ (F1.2, AGC ON),B/W: 0.002 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR

• Tiempo De Obturación1 s to 1/100,000 s

• Día Y NocheIR cut filter

• Ajuste De ÁnguloPan: -60° to 60°,tilt: 10° to 90°,rotate: 0° to 350°

• Lente

• Lente Varifocal lens, motorized lens, 2.8 to 8 mm

• Focal Length & FOV 2.8 to 8 mm, horizontal FOV 102.5° to 51.4°, vertical FOV 54.6° to 28.9°, diagonal FOV 122.7° to 59.2°

• Montura Del LenteØ14

• Enfoque Semi-auto,Manual

• AperturaF1.9

• Iluminador

• Tipo De Luz Suplementaria IR

• Rango De Luz Suplementaria Up to 30 m

• IR Wavelength 850 nm

• Vídeo

• Main Stream

  50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 25 fps (2688 × 1520), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (704 × 576, 640 × 480)

  60 Hz: 30 fps (704 × 480, 640 × 480)

• Compresión De Video

  Main stream: H.265+/H.265/H.264+/H.264,

  Sub-stream: H.265/H.264/MJPEG

• Vídeo Bitrate 32 Kbps to 16 Mbps

• Tipo H.264 Baseline Profile,Main Profile,High Profile

• Tipo H.265 Main Profile

• Codificación De Video Escalable (SVC) H.264 encoding

• Región De Interés (ROI)4 fixed regions for each stream

• Recorte ObjetivoYes

• Audio

• Compresión De AudioG.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

• Velocidad De Bits De Audio64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)

• Frecuencia De Muestreo De Audio 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz

• Filtro De Ruido AmbientalYes

• Red

• Protocolos TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour

• Vista En Vivo SimultáneaUp to 20 channels

• API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP

• Usuario/Operador

  Up to 32 users

  3 user levels: administrator, operator, and user

• Seguridad Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface

• Almacenamiento En Red

  NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),

  Together with high-end Hikvision memory card, memory card encryption and health detection are supported.

• Cliente iVMS-4200,Hik-Connect,Hik-Central

• Navegador Web

  Plug-in required live view: IE 10, IE 11,

  Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,

  Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

• Imagen

• Configuración De Imagen Rotate mode,saturation,brightness,contrast,sharpness,AGC,white balance,adjustable by client software or web browser

• Interruptor Día/Noche Day,Night,Auto,Schedule,Alarm Trigger

• Wide Dynamic Range (WDR) 120 dB

• SNR ≥ 52 dB

• Image Stabilization EIS

• Mejora De La Imagen BLC,HLC,3D DNR,Defog

• Superposición De Imagen LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format.

• Interfaz

• Ethernet Interface 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port

• On-Board Storage Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB

• Audio

  1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,

  1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

• Alarma 2 inputs, 2 outputs (max. 24 VDC, 1 A)

• RS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)

• Reset Key Yes

• Evento

• Evento Básico Motion detection,video tampering alarm,network disconnected,IP address conflict,illegal login,HDD full,HDD error

• Evento Inteligente Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection,scene change detection

• LinkageUpload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture

• General

• Alimentación

  12 VDC ± 20%, 1.2 A, max. 14.4 W,

  24 VAC ± 20%, 0.92 A, max. 14.8 W,

  PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.33 A to 0.24A, max. 14 W

• Dimensión Ø250 mm × 114.9 mm (Ø9.8" × 4.5")

• Dimensión Del Paquete

• 336 mm × 261 mm × 293 mm (13.2" × 10.3" × 11.5")

• Approx. 2.2 kg (4.9 lb.)

• Con Peso Del PaqueteApprox. 3.9 kg (8.6 lb.)

• Condiciones De Almacenaje-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing)

• Condiciones De Inicio Y Funcionamiento-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

• Idioma 33 idiomas: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

• Función General flash log,password protection,one-key reset

• Certificaciones

• EMC

  CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 50121-4: 2016+A1:2019,

  RCM: AS/NZS CISPR 32: 2015,

  IC: ICES-003: Issue 7,

  KC: KN32: 2015, KN35: 2015

• Seguridad

  UL: UL 62368-1,

  CB: IEC 62368-1: 2014+A11,

  CE-LVD: EN 62368-1: 2014/A11: 2017,

  BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005

• Ambiente

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006

• Protección IP67: IEC 60529-2013,IK10: IEC 62262:2002
